| Inlet Diameter | 203.2 mm (8.00 inch) |
| Outlet Diameter | 177.8 mm (7.00 inch) |
| Body Diameter Maximum | 406.4 mm (16.00 inch) |
| Body Length | 463.55 mm (18.25 inch) |
| Overall Length | 539.7 mm (21.25 inch) |
| Rated Flow LR | 38.5 m³/min (1360 cfm) |
| Rated Flow MR | 43.3 m³/min (1529 cfm) |
| Rated Flow HR | 46.4 m³/min (1639 cfm) |
| Restriction LR | 152 mm H2O (5.98 inch H2O) |
| Restriction MR | 203 mm H2O (7.99 inch H2O) |
| Restriction HR | 254 mm H2O (10.00 inch H2O) |
| Family | EBB |
