| Inlet Diameter | 63.5 mm (2.50 inch) |
| Outlet Diameter | 63.4 mm (2.50 inch) |
| Body Diameter Maximum | 151.1 mm (5.95 inch) |
| Body Length | 326 mm (12.83 inch) |
| Overall Length | 401.5 mm (15.81 inch) |
| Rated Flow LR | 3.3 m³/min (117 cfm) |
| Rated Flow MR | 3.9 m³/min (138 cfm) |
| Rated Flow HR | 4.4 m³/min (155 cfm) |
| Restriction LR | 152 mm H2O (5.98 inch H2O) |
| Restriction MR | 203 mm H2O (7.99 inch H2O) |
| Restriction HR | 254 mm H2O (10.00 inch H2O) |
| Family | FKB |
| Brand | Cycloflow™ |
