| Inlet Diameter | 76.2 mm (3.00 inch) |
| Outlet Diameter | 76.2 mm (3.00 inch) |
| Body Diameter Maximum | 180 mm (7.09 inch) |
| Body Length | 330.4 mm (13.01 inch) |
| Overall Length | 407.9 mm (16.06 inch) |
| Rated Flow LR | 4.4 m³/min (155 cfm) |
| Rated Flow MR | 5.2 m³/min (184 cfm) |
| Rated Flow HR | 5.9 m³/min (208 cfm) |
| Restriction LR | 152 mm H2O (5.98 inch H2O) |
| Restriction MR | 203 mm H2O (7.99 inch H2O) |
| Restriction HR | 254 mm H2O (10.00 inch H2O) |
| Family | FKB |
| Brand | Cycloflow™ |
