| Inlet Diameter | 101.6 mm (4.00 inch) |
| Outlet Diameter | 101.6 mm (4.00 inch) |
| Body Diameter Maximum | 231.3 mm (9.11 inch) |
| Body Length | 359.4 mm (14.15 inch) |
| Overall Length | 445 mm (17.52 inch) |
| Rated Flow LR | 7.4 m³/min (261 cfm) |
| Rated Flow MR | 8.9 m³/min (314 cfm) |
| Rated Flow HR | 10.2 m³/min (360 cfm) |
| Restriction LR | 152 mm H2O (5.98 inch H2O) |
| Restriction MR | 203 mm H2O (7.99 inch H2O) |
| Restriction HR | 254 mm H2O (10.00 inch H2O) |
| Family | XRB |
| Brand | Cycloflow™ |
| Primary Application | VERMEER 163670065 |
