| Inlet Diameter | 152.4 mm (6.00 inch) |
| Outlet Diameter | 128.1 mm (5.04 inch) |
| Body Diameter Maximum | 330.8 mm (13.02 inch) |
| Body Length | 523.4 mm (20.61 inch) |
| Overall Length | 601.4 mm (23.68 inch) |
| Rated Flow LR | 13.9 m³/min (491 cfm) |
| Rated Flow MR | 16 m³/min (565 cfm) |
| Rated Flow HR | 17.8 m³/min (629 cfm) |
| Restriction LR | 152 mm H2O (5.98 inch H2O) |
| Restriction MR | 203 mm H2O (7.99 inch H2O) |
| Restriction HR | 254 mm H2O (10.00 inch H2O) |
| Family | XRB |
| Brand | Cycloflow™ |
