| Inlet Diameter | 95.2 mm (3.75 inch) |
| Outlet Diameter | 89 mm (3.50 inch) |
| Body Diameter Maximum | 203 mm (7.99 inch) |
| Body Length | 397 mm (15.63 inch) |
| Overall Length | 453.5 mm (17.85 inch) |
| Rated Flow LR | 4.8 m³/min (170 cfm) |
| Rated Flow MR | 6.8 m³/min (240 cfm) |
| Rated Flow HR | 8.5 m³/min (300 cfm) |
| Restriction LR | 100 mm H2O (3.94 inch H2O) |
| Restriction MR | 200 mm H2O (7.87 inch H2O) |
| Family | ELB |
